Baumann is very proud to introduce our new plastering machine PM5 and PM 5X. The universal worm pump for dry mix and wet mortar from bag or silo. The modular system of PM 5 series is suitable for users who pump and spray pumpable wet mortars with grain size of up to 6mm. Their versatility and reliability are inspiring users in all sector throughout the world.
Baumann develop and supply international standard superior quality machines and Baumann Machines are certified by CE, TüV, GS and ISO9001.
Special Features:
- Innovative Shield Design
- Geared Motor with safety lock ( no unintentional speed change )
- Compressor support plate
- Plug & Play ! Machine comes complete with mortar hose, air hose, spray gun, nozzle and remote control
- PM5X is certified TUV, CE and GS !
- Wear parts and accessories exchangable with Putzmeister S5 series !
| Technical Data |
PM 5 |
PM 5X |
| Versions |
— |
with pan mixer 100 |
| Worm Pump |
2L6 |
2L6 |
| Delivery rate* |
7-40 l/min |
7-40 l/min |
| Delivery pressure |
40 bar |
40 bar |
| Delivery distance* |
60 m |
60 m |
| Delivery height* |
40 m |
40 m |
| Drive motor |
5.5kW, 400V |
5.5kW, 400V |
| Drive worm pump |
Variable drive |
Variable drive |
| Mixer Drive |
— |
2.2kW, 400V |
| L×W×H |
2,290×680×650 mm |
2,290×680×1,150 mm |
| Maximum grain size |
6 mm |
6 mm |
| Discharge connection |
M 35 |
M 35 |
| Part no. |
B99 254 0010 |
B99 254 0030 |
*The data is based on experience and depends on the material used.
Application:
Suitable for a big variety of mortars such as:
--Base coat --Fire proofing mortars
--Lime cement mixed mortars --Self leveling mortars
--Insulation coatings --Grouting materials
--Texture coatings --Concrete repair mortars
--Masonry mortar --Anchoring mortar
With a variable output, from approx. 7-40 l/min, the PM 5 and PM 5X can be adjusted to any type of application.
|
